Dynamics (Dynamic) |409
d Wet/Dry Dry,
1:99…99:1,
Wet
Balance between the wet and dry signal
Src Of f…Tempo See DMS (Dynamic Modulation Source)
Amt –100…+100 Amount of modulation source
5: Stereo Gate
This effect mutes the input signal when it falls below a specified level. You
can also invert the on/off status of the gate, or use note-on/off messages to
turn the gate on/off directly.
Left
Right
FX Control BUS 1
FX Control BUS 2
FX Amt
FX Amt
Stereo In - Stereo Out
Envelope Source
Gain Adjust
Gain Adjust
Side PEQ
Envelope - Control
Envelope - Control
Trigger Monitor
+
Envelope Select
Gate
Delay
Gate
Delay
D
-mod
a Envelope Source D-mod, Input Selects the source to control the gate:
D-mod control, or use the input signal
as a trigger
b Envelope Select L/R Mix,
L Only,
R Only
Selects the control signal: left and right
linked, left only, or right only
Src Of f…Tempo Selects the source that will control the
gate when Envelope Src = D-mod
c Threshold 0 …10 0 Sets the level at which gating is applied
Polarity +, – Switches the polarity of gating
d Attack 1…10 0 Sets the attack time
Release 1…10 0 Sets the release time
e Delay Time [msec] 0…10 0 Sets the delay time for the gate input
f Side PEQ Insert Off, On Switches the trigger signal equalizer on/
off
Trigger Monitor Off, On Switches between monitoring the effect
output and the trigger signal
