156| Advanced editing of the Sound sets
Input sensitivity and bypassing
The EQ Control page lets you set the input sensitivity and bypass EQ on each
channel.
Access the EQ Control page
▪ Go to the Mixer/Tuning > EQ Control page.
Trim the EQ input
Extreme equalization gains can overload the audio circuits and lead to dis-
tortion. You can however trim the input to avoid overloading.
▪ Use the Input Trim knobs to limit the level of the signal passing through the
equalizer.
Input Trim Meaning
0 … 99 Limiting value. The higher, the most effective it is.
Bypass the EQ
▪ Select the Bypass checkbox on the mixer channel you want to exclude from
equalization.
▪ Deselect the Bypass checkbox to activate the EQ again.
