Korg HAVIAN 30

Setting the Drum Kit’s basic parameters |345
Use the numeric field next to the sample name to choose the sample inside
the selected bank.
Bank Meaning
ROM Factory samples, supplied by Korg as standard.
RAM User samples, loaded when loading some User Drum Kits. (Only
available on some models).
The sample you select for the current layer will be triggered by velocities
higher than the value of the velocity switches. If you do not wish to use veloc-
ity switching, assign just one layer to the selected key, and assign a sample
only to layer 1.
If you create a new Drum Kit based on RAM samples, the RAM samples must
be loaded from the internal memory or from a device connected to the USB
HOST port. In case samples are not loaded, no sound will be heard, even if
the Drum Kit can be selected and its name appears in the display.
Each sample has an upper note range limit, and may not produce sound
when played above that limit.
▪ Select the Rev (Reverse) checkbox to play the sample in reverse. In the case
of samples that were originally specified to loop, the sample will be played
back in one-shot reverse mode. If the sample was originally set to reverse, it
will playback without change.
Setting a sample start offset
▪ Use the Ofs (Offset) parameter to specify the point where the sample will
start to play. With some samples this parameter will not be available.
Offset Meaning
Off The sound will start from the beginning of the sample.
1st…6th The sound will begin from the offset location pre-determined for
each sample.
NoAtk The initial portion of the multisample is ignored.
AMS Activates the Alternate Modulation Source (see below).
PseudoRandom (Only works when more than one Offset point is available in the
multisample). Randomly selects one of the available Offset points
(including Attack and Off).
