Korg HAVIAN 30

Delay |531
70: Tape Echo BPM
This is a tape echo that lets you synchronize the delay time to the tempo of
the song.
Wah Flatter
D
-mod
Tap2/3 Position
+
Tape
Saturation
Left
Right
FX Amt
Trim
PanLevel
FX Amt
FX Amt = 100: Mono In - Stereo Out / FX Amt = 0: Stereo In - Stereo Out
Feedback
Feedback Amt
High / Low DampPre Tone
Delay
(1)
(2)
(3)
Delay Time
PM
PM
ase ote  Times
Tempo
a BPM (Delay) MIDI,
40.00…
300.00
MIDI syncs to the system tempo; 40–300
sets the tempo manually for this individual
effect
Tap1 Dmod Src Of f…Tempo Selects the modulation source of the delay
time
b Tap1 Delay Note
…
Selects the type of notes to specify the delay
time (tap1)
Times x1…x32 Sets the number of notes to specify the delay
time (tap1)
Time Over? ---, OVER! Displays an error message when the delay
time exceeds the upper limit
c Tap1 Dmod Note
…
Selects the note value used to specify the
delay time when the modulation is at maxi-
mum
Times x1…x32 Species the number of notes used to spec-
ify the delay time when the modulation is at
maximum
d Tap2 Position [%] 0…10 0 Sets the position of Tap 2 relative to the Tap 1
delay time the depth of pitch variation
e Tap3 Position [%] 0…10 0 Sets the position of Tap 3 relative to the Tap 1
delay time the depth of pitch variation
f Tap1 Level 0…10 0 Sets the Tap1 output level
Pan L, 1…99, R Sets the stereo image of tap1
FB Amt –100…+100 Sets the Tap1 feedback amount
