Korg HAVIAN 30 - Page 460

456| Effects for the MIDI Sounds
a LFO Frequency [Hz] 0.02…13.00 Sets the speed of the LFO
b Tap1 (000) [msec] 0…1000 Sets the Tap1 (LFO phase=0 degrees)
delay time
Depth 0…30 Sets the Tap1 chorus depth
Level 0…30 Sets the Tap1 output level
Pan L6…L1, C,
R1…R6
Sets the Tap1 stereo image
c Tap2 (180) [msec] 0…1000 Sets the Tap2 (LFO phase=180 degrees)
delay time
Depth 0…30 Sets the Tap2 chorus depth
Level 0…30 Sets the Tap2 output level
Pan L6…L1, C,
R1…R6
Sets the Tap2 stereo image
d Tap3 (090) [msec] 0…1000 Sets the Tap3 (LFO phase=90 degrees)
delay time
Depth 0…30 Sets the Tap3 chorus depth
Level 0…30 Sets the Tap3 output level
Pan L6…L1, C,
R1…R6
Sets the Tap3 stereo image
e Tap4 (270) [msec] 0…1000 Sets the Tap4 (LFO phase=270 degrees)
delay time
Depth 0…30 Sets the Tap4 chorus depth
Level 0…30 Sets the Tap4 output level
Pan L6…L1, C,
R1…R6
Sets the Tap4 stereo image
f Tap1 Feedback –100…+100 Sets the Tap1 feedback amount
Src Off…Tempo Selects the modulation source of Tap1
feedback amount and effect balance
Amt –100…+100 Sets the Tap1 feedback amount and
modulation amount
g Wet/Dry Dry,
1:99…99:1,
Wet
Balance between the wet and dry signal
Src Off…Tempo See DMS (Dynamic Modulation Source)
Amt –100…+100 Amount of modulation source
