Modulation and Pitch Shift (Mod./P.Shift) |471
f MIDI Sync Off, On When this is on, the LFO speed is set by BPM,
Base Note, and Times, instead of Frequency
BPM MIDI,
40.00…
300.00
MIDI syncs to the system tempo; 40–300
sets the tempo manually for this individual
effect
Base Note
r… w
Selects the type of notes that specify the LFO
speed
Times x1…x32 Sets the number of notes that specify the
LFO speed
g Depth 0…10 0 Sets the depth of LFO modulation
Src Of f…Tempo Selects the modulation source of the LFO
modulation depth
Amt –100…+100 Sets the modulation amount of the LFO mod-
ulation depth
h Wet/Dry Dry,
1:99…99:1,
Wet
Balance between the wet and dry signal
Src Of f…Tempo See DMS (Dynamic Modulation Source)
Amt –100…+100 Amount of modulation source
a: AUTOFADE Src
b: Fade-In Delay [msec]
b: Fade-In Rate
d: LFO Frequency Mod
When “LFO Frequency Mod” is set to AUTOFADE, you can use the modula-
tion source selected in “AUTOFADE Src” as a trigger to automatically fade in
the modulation amount. When “MIDI Sync” is set to On, you cannot use this.
The “Fade-In Rate” parameter specifies the rate of fade-in. The “Fade-In De-
lay” parameter determines the time from AutoFade modulation source On
until the fade-in starts.
The following is an example of fade-in where the LFO speed is increased
from “1.0Hz” to “4.0Hz” when a note-on message is received.
AUTOFADE Src=Gate1, LFO Frequency Mod=AUTOFADE, LFO Frequency
[Hz]=1.0, Amt=3.0
The effect is off when a value for the dynamic modulation source speci-
fied for the “AUTOFADE Src” parameter is smaller than 64, and the effect is
