Modulation and Pitch Shift (Mod./P.Shift) |491
a OSC Mode Fixed, Note
(Key Follow)
Switching between specifying the oscilla-
tor frequency and using a note number
Pre LPF 0 …10 0 Sets the damping amount of the high range
input to the ring modulator
b Fixed Frequency
[Hz]
0…12 . 0 0 k Sets the oscillator frequency when OSC
Mode is set to Fixed
Src Of f…Tempo Selects the modulation source for the os-
cillator frequency when OSC Mode is set
to Fixed
Amt –12.00k…
+12.0 0 k
Sets the modulation amount of the oscil-
lator frequency when OSC Mode is set to
Fixed
c Note Offset –48…+48 Sets the pitch difference from the original
note when OSC Mode is set to Note (Key
Follow)
Note Fine –100…+100 Fine-adjusts the oscillator frequency
d LFO Frequency
[Hz]
0.02…20.00 Sets the speed of the LFO
Src Of f…Tempo Selects a modulation source for LFO speed
Amt –20.00…
+20.00
Sets the modulation amount of LFO speed
e MIDI Sync Off, On When this is on, the LFO speed is set by
BPM, Base Note, and Times, instead of
Frequency
BPM MIDI,
40.00…
300.00
MIDI syncs to the system tempo; 40–300
sets the tempo manually for this individual
effect
Base Note
…
Selects the type of notes that specify the
LFO speed
Times x1…x32 Sets the number of notes that specify the
LFO speed
f LFO Depth 0 …10 0 Sets the depth of LFO modulation for the
oscillator frequency
Src Of f…Tempo Selects the modulation source of the depth
of modulation
Amt –100…+100 Sets the modulation amount of the depth
of modulation
g Wet/Dry Dry,
1:99…99:1,
Wet
Balance between the wet and dry signal
Src Of f…Tempo See DMS (Dynamic Modulation Source)
Amt –100…+100 Amount of modulation source
To Next Page
