The xxPCFG register is used to map redirectable concurrent inputs to any port.
Register name
Register settings
Function
TI10PCFG/
TI11PCFG/
TI12PCFG/
TI13PCFG/
INTP0PCFG/
INTP1PCFG/
INTP2PCFG/
INTP3PCFG/
SDI00PCFG/
SCLKI00PCFG/
SS00PCFG/
SDI20PCFG/
SCLKI20PCFG/
SDAA0PCFG/
SCLA0PCFG/
RXD1PCFG
6'h00
Concurrent input does not map to any port
6'h01
Maps to P00
6'h02
Map to P01
6'h03
Map to P10
6'h04
Maps to P11
6'h05
Map to P12
6'h06
Map to P13
6'h07
Maps to P14
6'h08
Maps to P15
6'h09
Maps to P16
6'h0a
Maps to P17
6'h0b
Maps to P20
6'h0c
Map to P21
6'h0d
Maps to P22
6'h0e
Maps to P23
6'h0f
Maps to P24
6'h10
Maps to P25
6'h11
Map to P26
6'h12
Map to P27
6'h13
Maps to P30
6'h14
Maps to P31
6'h15
Map to P40
6'h16
Maps to P41
6'h17
Maps to P50
6'h18
Map to P51
6'h19
Map to P60
6'h1a
Map to P61
6'h1b
Maps to P62
6'h1c
Maps to P63
6'h1d
Maps to P70
6'h1e
Maps to P71
6'h1f
Map to P72
6'h20
Maps to P73
6'h21
Maps to P74
6'h22
Maps to P75
6'h23
Maps to P120
6'h24
Maps to P121
6'h25
Maps to P122
6'h26
Maps to P123
6'h27
Maps to P124
6'h28
Maps to P130
6'h29
Maps to P136
6'h2a
Maps to P137
6'h2b
Maps to P140
6'h2c
Maps to P146
6'h2d
Maps to P147
