Figure 12-87 Slave select input function (SSPI00) Example of register setting content when slave send and

receive (2/2)

(f) serial channel start register m (SSm) Only set bit of target channel to 1.

(g) input switch control register (ISC)This is controlled by SS00 pin of SSPI00 slave channel (channel 0 of unit 0).

0: SS00 pin input invalid

1: SS00 pin input valid

Note Data must be sent to the SIOp register settings before the master device starts the output clock.

Notice 1.m: Unit number (m=0) n: Channel number (n=0)p:SSPI number (p=00)

2. : Fixed in Slave Receive mode. : Cannot be set (initial value).

×: This is the bit that cannot be used in this mode (set the initial value if it is not used in other modes either).

0/1: Set 0 or 1 according to the user's purpose.
