V1.2.2

CMS32L051 User Manual |Chapter 14 Serial interface IICA

www.mcu.com.cn 481 / 703

An example of the structure of a serial bus is shown in Figure 14-2.

Figure 14-2 Example of a serial bus structure for a I2C bus

SCLAn

SDAAn

SCLAn

SDAAn

SCLAn

SDAAn

SCLAn

SDAAn

SCLAn

SDAAn

master control CPU2

slave CPU2

address 1

slave CPU3

address 2

address 3

slave IC

address N

slave IC

master CPU1

slave CPU1

address 0

serial data bus

serial clock

Note n=0
