CMS32L051 User Manual |Chapter 14 Serial interface IICA

www.mcu.com.cn 538 / 703

(d)

Start~Address~Data~Start~Address~Data~Stop

(i) When WTIMn=0 (different addresses after restart (non-extension)).

ST AD6~AD0 R/W ACK D7~D0 ACK

1:IICSn=0001X110B

2:IICSn=0001X000B

4:IICSn=00000001B

备注

must generate

only generate while SPIEn bit is '1'

any

ST AD6~AD0 R/W ACK D7~D0 ACK

3:IICSn=00000110B

(ii) When WTIMn=1 (different addresses after restarting (non-extension)).

ST AD6~AD0 R/W ACK D7~D0 ACK

1:IICSn=0001X110B

2:IICSn=0001XX00B

4:IICSn=00000001B

ST AD6~AD0 R/W ACK D7~D0 ACK

3:IICSn=00000110B

Remark must generate

only generate while SPIEn bit is '1'

any

Note n=0
