V1.2.2

CMS32L051 User Manual |Chapter 14 Serial interface IICA

www.mcu.com.cn 548 / 703

(ii) Extension code

ST AD6~AD0 R/W ACK D7~Dm ACK

1:IICSn=1000X110B

2:IICSn=01000010B

3:IICSn=00000001B

ST AD6~AD0 R/W ACK D7~D0 ACK

set LRELn bit to '1' via software

m=0~6

Remark must generate

only generate while SPIEn bit is '1'

any

(e) A situation in which arbitration fails at the time of transmission due to a stop condition

ST AD6~AD0 R/W ACK D7~Dm SP

1 2

1:IICSn=10000110B

2:IICSn=01000001B

m=0~6

Remark must generate

only generate while SPIEn bit is '1'

Note n=0
