CMS32L051 User Manual |Chapter 20 Standby Function

www.mcu.com.cn 629 / 703

function

General CRC

When DMA is executed in the operation of the RAM area, it can be run.

RAM parity function

It can run when performing DMA.

SFR protection function

Note Stop running: Automatically stops running when transferred to sleep mode.

Disable Running: Stop running before moving to sleep mode.

IH: High Speed Internal Oscillator Clock fIL: Low Speed Internal Oscillator Clock

fX: X1 clock fEX: External master system clock

fXT: XT1 clock fEXS: External subsystem clock
