V1.2.2

CMS32L051 User Manual |Chapter 24 Security Features

www.mcu.com.cn 671 / 703

< Operation Flow >

Figure 24-3 Flow chart of flash CRC operation function (high-speed CRC)

Start

configure FEA5~FEA0 bit

Yes

normal

completion

CRC0EN=0

CRC0EN=1

PGCRCL=0000H

PGCRCH=00H

execute WFE instruction

CRC calculation

completes.

read value of

PGCRCL，PGCRCH

compare with the

expectation value of

CRC

same

difference

abnormal

compeltion

configure CRC calculation range

allows CRC calculation

perform initialization of CRC

calculation result register

start CRC calculation via

WFE instruction

disable CRC calculation

read CRC calculation result

save expected value of CRC

calculation result to last 4 bytes

ahead of time

compare with the pre-stored

expectation value

Note 1. Only the code flash memory is an object for CRC operations.

2. The expected value of the CRC operation must be saved in the area behind the operation range in the code flash.
