CMS32L051 User Manual |Chapter 4 Clock Generation Circuit

www.mcu.com.cn 75 / 703

Figure 4-8 Format of peripheral enable register 1 (PER1)

Address: 4002081AH After reset: 00H R/W

symbol

PER1

SPIEN

Provides control of the input clock of the SPI

Stop supplying the input clock.

 cannot run.

An input clock is provided.

 can run.

DMAEN

Provides control of the input clock of the DMA

Stop supplying the input clock.

 cannot be run.

An input clock is provided.

 can run.

EPWMIN

Provides control of the EPWM's input clock

Stop supplying the input clock.



An input clock is provided.



SPIEN

DMAEN

EPWMEN
