CMS32L051 User Manual |Chapter 4 Clock Generation Circuit

www.mcu.com.cn 83 / 703

Figure 4-17 Example of an incorrect resonator connection (2/2)

(e) varying high current source close to singal lines

(f) Current flows along grounding of oscilation circuit

(Point A, B, C has difference in electric potential)

high current

(g) extracted signal

Note When X2 and XT1 are routed in parallel, the crosstalk noise of X2 will superimpose on XT1 and cause malfunction.

Note In the case of a subsystem clock, replace X1 and X2 with XT1 and XT2 respectively when reading, and insert a

series resistor on the XT2 side.
