Configuring Link Layer Discovery Protocol and LLDP-MED
6-14 Discovery Protocol Configuration
Commands
Theî ±commandsî ±usedî ±toî ±reviewî ±andî ±configureî ±theî ±CDPî ±discoveryî ±protocolî ±areî ±listedî ±below.î ±
Step Task Command(s)
1. Configure global system LLDP parameters set lldp tx-interval
set lldp hold-multiplier
set lldp trap-interval
set lldp med-fast-repeat
clear lldp
2. Enable/disable specific ports to:
• Transmit and process received LLDPDUs
• Send LLDP traps
• Send LLDP-MED traps
set/clear lldp port status
set/clear lldp port trap
set/clear lldp port med-trap
3. Configure an ECS ELIN value for specific ports set/clear lldp port location-info
4. Configure Network Policy TLVs for specific ports set/clear lldp port network-policy
5. Configure which optional TLVs should be sent by
specific ports. For example, if you configured an
ECS ELIN and/or Network Policy TLVs, you must
enable those optional TLVs to be transmitted on
the specific ports.
set/clear lldp tx-tlv
For information about... Refer to page...
show lldp 6-15
show lldp port status 6-15
show lldp port trap 6-16
show lldp port tx-tlv 6-17
show lldp port location-info 6-17
show lldp port local-info 6-18
show lldp port remote-info 6-21
show lldp port network-policy 6-22
set lldp tx-interval 6-23
set lldp hold-multiplier 6-24
set lldp trap-interval 6-24
set lldp med-fast-repeat 6-25
set lldp port status 6-25
set lldp port trap 6-26
set lldp port med-trap 6-26
set lldp port location-info 6-27
set lldp port tx-tlv 6-28
set lldp port network-policy 6-29
