access-list (extended)
22-84 Authentication and Authorization Configuration
Defaults
Ifinsert,replaceormovearenotspecified,thenewentrywillbeappendedtotheaccesslist.
Ifsource2isnotspecifiedwithmove,onlyoneentrywillbemoved.
Mode
Globalconfiguration:B5(su)‐>router(Config)#
Usage
ValidaccesslistnumbersforstandardACLsare1to99.ForextendedACLs,validvaluesare100
to199.
Accesslistsareappliedtointerfacesbyusingthe
ipaccess‐groupcommand(page22‐86).
Allaccesslistshaveanimplicit“denyanyany”statmentastheirlastentry.
Examples
Thisexampleshowshowtocreateaccesslist1withthreeentriesthatallowaccesstoonlythose
hostsonthethreespecifiednetworks.Thewildcardbitsapplytothehostportionsofthenetwork
addresses.Anyhostwithasourceaddressthatdoesnotmatchtheaccesslistentrieswill
be
rejected:
B5(su)->router(Config)#access-list 1 permit 192.5.34.0 0.0.0.255
B5(su)->router(Config)#access-list 1 permit 128.88.0.0 0.0.255.255
B5(su)->router(Config)#access-list 1 permit 36.0.0.0 0.255.255.255
Thisexamplemovesentry16tothebeginningofACL22:
B5(su)->router(Config)#access-list 22 move 1 16
access-list (extended)
UsethiscommandtodefineanextendedIPaccesslistbynumberwhenoperatinginroutermode.
Thenoformofthiscommandremovesthedefinedaccesslistorentry:
Syntax
To create an extended ACL entry:
access-list access-list-number {deny | permit} protocol source [source-wildcard]
[eq port] destination [destination-wildcard] [eq port]
no access-list access-list-number [entryno [entryno]]
To insert or replace an ACL entry:
access-list access-list-number insert | replace entryno {deny | permit} protocol
source [source-wildcard] [eq port] destination [destination-wildcard] [eq port]
insert|replace
entryno
(Optional)InsertsthisnewentrybeforeaspecifiedentryinanexistingACL,
orreplacesaspecifiedentrywiththisnewentry.
movedestination
source1source2
(Optional)Movesasequenceofaccesslistentriesbeforeanotherentry.
Destinationisthenumberoftheexistingentrybeforewhichthis
newentry
willbemoved.Source1isasingleentrynumberorthefirstentrynumberin
therangetobemoved.Source2(optional)isthelastentrynumberinthe
rangetobemoved.Ifsource2isnotspecified,onlythesource1entrywillbe
moved.
