Dynamic ARP Inspection Overview
Enterasys B5 CLI Reference 17-19
Example Configuration
ThefollowingexampleconfiguresDHCPsnoopinganddynamicARPinspectioninarouting
environmentusingRIP.Theexampleconfigurestwointerfacesonthe switch,configuringRIPon
bothinterfaces,assigningeachtoadifferentVLAN,andthenenablingDHCPsnoopingand
dynamicARPinspection onthem:
•Interfacege.1.1,whichisconnected
toaremoteDHCPserver,onVLAN192
•Interfacege.1.2,whichisconnectedtoDHCPclients,onVLAN10
Inaddition,thedefaultVLAN,VLAN1,isalsoenabledforDHCPsnoopinganddynamicARP
inspection.
SincetheDHCPserverisremote,theswitchhasbeenconfiguredasaDHCPrelayagent
(withthe
iphelper‐addresscommand),toforwardclientrequeststotheDHCPserver.Therefore,MAC
addressverificationisdisabled(withthesetdhcpsnoopingverifymac‐addressdisable
command)inordertoallowDHCPRELEASEpacketstobeprocessedbytheDHCPsnooping
functionalityandclientbindingsremovedfromthebindings
database
Router Configuration
router
enable
configure
interface vlan 10
no shutdown
ip address 10.2.0.1 255.255.0.0
ip helper-address 192.168.0.200
ip rip send version 2
ip rip receive version 2
ip rip enable
exit
interface vlan 192
no shutdown
ip address 192.168.0.1 255.255.255.0
ip rip send version 2
ip rip receive version 2
ip rip enable
exit
router rip
exit
VLAN Configuration
set vlan create 10
set vlan create 192
clear vlan egress 1 ge.1.1-2
T
Note: This example applies only to platforms that support routing.
