set rmon filter
15-20 RMON Configuration
B5(rw)->show rmon filter
Index= 55508 Channel Index= 628 EntryStatus= valid
----------------------------------------------------------
Data Offset 0 PktStatus 0
PktStatusMask 0 PktStatusNotMask 0
Owner ETS,NAC-D
-----------------------------
Data
ff ff ff ff ff ff
-----------------------------
DataMask
ff ff ff ff ff ff
-----------------------------
DataNotMask
00 00 00 00 00 00
set rmon filter
UsethiscommandtoconfigureanRMONfilterentry.
Syntax
set rmon filter index channel-index [offset offset] [status status] [smask smask]
[snotmask snotmask] [data data] [dmask dmask] [dnotmask dnotmask] [owner owner]
Parameters
Defaults
Ifownerisnotspecified,itwillbesettomonitor.
Ifnootheroptionsarespecified,none(0)willbeapplied.
index Specifiesanindexnumberforthisentry.Anentrywillautomaticallybe
createdifanunusedindexnumberischosen.Maximumnumberof
entriesis10.Maximum valueis
65535.
channel‐index Specifiesthechanneltowhichthisfilterwillbeapplied.
offsetoffset (Optional)Specifiesanoffsetfromthebeginningofthepackettolookfor
matches.
statusstatus (Optional)Specifiespacketstatusbitsthataretobematched.
smasksmask (Optional)Specifiesthemaskappliedtostatustoindicatewhich
bitsare
significant.
snotmasksnotmask (Optional)Specifiestheinversionmaskthatindicateswhichbitsshould
besetornotset
datadata (Optional)Specifiesthedatatobematched.
dmaskdmask (Optional)Specifiesthemaskappliedtodatatoindicatewhichbitsare
significant.
dnotmaskdnotmask (Optional)Specifiestheinversionmaskthatindicateswhichbits
should
besetornotset.
owner (Optional)Specifiesthenameoftheentitythatconfiguredthisentry.
