Enterasys B5 CLI Reference 10-1

802.1Q VLAN Configuration

ThischapterdescribestheEnterasysB5system’scapabilitiestoimplement802.1QvirtualLANs

(VLANs).

VLAN Configuration Summary

VirtualLANsallowthenetworkadministratortopartitionnetworktrafficintologicalgroupsand

controltheflowofthattrafficthroughthenetwork.Oncethetrafficand,ineffect,theusers

creatingthetraffic,areassignedtoaVLAN,thenbroadcastandmulticasttrafficiscontained

withintheVLANandusers

canbeallowedordeniedaccesstoanyofthenetwork’sresources.

Also,someoralloftheportsonthedevicecanbeconfiguredasGVRPports,whichenableframes

receivedwithaparticularVLANIDandprotocoltobetransmittedonalimitednumberofports.

Thiskeeps

thetrafficassociatedwithaparticularVLANandprotocolisolatedfromtheotherparts

ofthenetwork.

Port String Syntax Used in the CLI

ForinformationonhowtodesignateVLANsandportnumbersintheCLIsynt ax,referto“Port

StringSyntaxUsedintheCLI”onpage 7‐1.

For information about... Refer to page...

VLAN Configuration Summary 10-1

Viewing VLANs 10-3

Creating and Naming Static VLANs 10-5

Assigning Port VLAN IDs (PVIDs) and Ingress Filtering 10-8

Configuring the VLAN Egress List 10-13

Setting the Host VLAN 10-18

Enabling/Disabling GVRP (GARP VLAN Registration Protocol) 10-20

Note: An Enterasys Networks Feature Guide document containing an in-depth discussion of VLAN

configuration is located on the Enterasys Networks web site:

https://extranet.enterasys.com/downloads/

Note: The device can support up to 1024 802.1Q VLANs. The allowable range for VLAN IDs is 1

to 4093. As a default, all ports on the device are assigned to VLAN ID 1, untagged.
