clear tftp timeout

3-48 Basic Configuration

clear tftp timeout

UsethiscommandtoresettheTFTPti meoutvaluetothedefaultvalueof2seconds.

Syntax

clear tftp timeout

Parameters

None.

Defaults

None.

Mode

Switchcommand,read‐write.

Example

Thisexampleshowshowtoclearthetimeoutvaluetothedefaultof2seconds.

B3(rw)-> clear tftp timeout

set tftp retry

UsethiscommandtoconfigurehowmanytimesTFTPwillresendapacket,eitheran

acknowledgementpacketoradatapacket.

Syntax

set tftp retry retry

Parameters

Defaults

None.

Mode

Switchcommand,read‐write.

Example

Thisexamplesetstheretrycountto3.

B3(rw)->set tftp retry 3

retry Specifiesthenumberoftimesapacketwillberesent.Thevalidrangeis

from1to1000.Defaultvalueis5retries.
