set diffserv policy rename

9-14 Differentiated Services Configuration

Defaults

None.

Mode

Switchcommand,read‐write.

Example

Thisexampleshowshowtosetthepolicyingactiontodropforpacketsnotconformingtothe

Diffservpolicy“admin,”class“system.”

B3(rw)->set diffserv policy police action nonconform drop admin system

set diffserv policy rename

UsethiscommandtochangethenameofaDiffservpolicy.

Syntax

set diffserv policy rename policyname newpolicyname

Parameters

Defaults

None.

Mode

Switchcommand,read‐write.

Example

Thisexampleshowshowtorenamethe“admin”Diffservpolicyto“system”:

B3(rw)->set diffserv policy rename admin system

policyname SpecifiesthepolicynamepreviouslysetforthisnewDiffservclass.

newpolicyname Specifiesanewpolicyname.
