show spantree bpdu-forwarding

SecureStack B3 Configuration Guide 7-9

Parameters

None.

Defaults

None.

Mode

Switchcommand,read‐write.

Example

ThisexampleshowshowtoresettheSpanningTreeversion:

B3(su)->clear spantree version

show spantree bpdu-forwarding

Use this command to display the Spanning Tree BPDU forwarding mode.

Syntax

show spantree bpdu-forwarding

Parameters

None.

Defaults

None.

Mode

Switchcommand,read‐only.

Example

ThisexampleshowshowtodisplaytheSpanningTreeBPDUforwardingmode:

B3(su)->show spantree bpdu-forwarding

BPDU forwarding is disabled.

set spantree bpdu-forwarding

UsethiscommandtoenableordisableSpanningTreeBPDUforwarding.BydefaultBPDU

forwardingisdisabled.

Syntax

set spantree bpdu-forwarding {disable | enable}

Parameters

disable|enable DisablesorenablesBPDUforwarding;.
