Installing a New Stackable System of Up to Eight Units
2-2 Configuring Switches in a Stack
•Theconsoleportonthemanagerswitchremainsactiveforoutofband(local)switch
management,buttheconsoleportoneachmemberswitchisdeactivated.Thisenablesyouto
settheIPaddressandsystempasswordusingasingleconsoleport.Noweachswitchcanbe
configuredlocallyusingonly
themanagersconsoleport,orinbandusingaremotedevice
andtheCLIsetofcommandsdescribedinthissection.
Onceastackiscreated(morethanoneswitchisinterconnected),thefollowingprocedureoccurs:
1. Bydefault,unitIDsarearbitrarilyassignedonafirstcome,firstservedbasis.
2. UnitIDs
aresavedagainsteachmodule.Then,everytimeaboardispowercycled,itwill
initializewiththesameunitID.Thisisimportantforportspecificinformation(forexample:
ge.4.12isthe12thGigabitEthernetportonUnit#4).
3. Themanagementelectionprocessusesthefollowingprecedencetoassign
amanagement
switch:
a. Previouslyassigned/electedmanagementunit
b. Managementassignedpriority(values115)
c. Hardwarepreferencelevel
d. HighestMACAddress
Usethefollowingrecommendedprocedureswheninstallinganewstackablesystemoraddinga
newunittoanexistingstack.
Installing a New Stackable System of Up to Eight Units
Usethefollowingprocedureforinstallinganewstackofuptoeightunitsoutofthebox.
1. Beforeapplyingpower,makeallphysicalconnectionswiththestackcablesasdescribedin
theSecureStackB3InstallationGuides.
2. Onceallofthestackcableshavebeenconnected,individuallypoweroneachunit
fromtopto
bottom.
3. (Optional)Ifdesired,changethemanagementunitusingthesetswitchmovemanagement
commandasdescribedinsetswitchmovemanagementonpage211.
4. Oncethedesiredmasterunithasbeenselected,resetthe systemusingthe resetcommandas
describedinresetonpage
351.
5. Afterthestackhasbeenconfigured,youcanusetheshowswitchunitcommand(“show
switchonpage26)tophysicallyidentifyeachunit.Whenyouenterthecommandwitha
unitnumber,theMGRLEDofthespecifiedswitchwillblinkfor10seconds.Thenormal
state
ofthisLEDisoffformemberunitsandsteadygreenforthemanagerunit.
Important
The following procedures assume that all units have a clean configuration from manufacturing. When adding
a new unit to an already running stack, it is also assumed that the new unit is using the same firmware image
version as other units in the stack.
Notes: Ensure that each switch is fully operational before applying power to the next switch.
Since unit IDs are assigned on a first-come, first-served basis, this will ensure that unit IDs are
ordered sequentially.
Once unit IDs are assigned, they are persistent and will be retained during a power cycle to any or
all of the units.
