set lldp trap-interval

4-24 Discovery Protocol Configuration

B3(rw)->set lldp hold-multiplier 5

set lldp trap-interval

UsethiscommandtosettheminimumintervalbetweenLLDPnotificationssentbythisdevice.

LLDPnotificationsaresentwhenaremotesystemchangehasbeendetected.

Syntax

set lldp trap-interval frequency

Parameters

Defaults

None.

Mode

Switchcommand,read‐write.

Example

ThisexamplesetstheminimumintervalbetweenLLDPtrapsto10seconds.

B3(rw)->set lldp trap-interval 10

frequency SpecifiestheminimumtimebetweenLLDPtraptransmissions,in

seconds.Thevaluecanrangefrom5to3600seconds.Thedefault

valueis5seconds.
