Enterasys SecureStack B3 User Manual

set cos reference
10-28 Policy Classification Configuration
Example
Thisexampleclearsthedatarateto0forIRLresourceindex1forgroup2.0.
B3(su)->clear cos port-resource irl 2.0 1 rate
set cos reference
UsethiscommandtosettheClassofServiceinboundratelimitingreferenceconfiguration.
Syntax
set cos reference irl group-type-index reference rate-limit irl-index
Parameters
Defaults
None.
Mode
Switchcommand,read‐write.
Usage
TheCoSreferencetablemapstheuser‐definedIRLreferencesfoundintheCoSsettingstable(see
“setcossettings”onpage 10‐20)toratelimiterscreatedintheportresourcetable(see“setcos
port‐resource”onpage 10‐25).TheCoSreferencetableindexescanbethoughtof
asvirtualrate
limiters.Thetableaccountsforthemaximumnumberofratelimiterssupportedbythedevice.
Thevirtuallimitersthenmaptothephysicalratelimiters.TheCoSIRLReferenceTableisnot
configuredbydefault.
TheCoSIRLreferencetableuses100indexesorvirtualratelimiters,and
mapseachvirtuallimiter
toaphysicallimiterorresource.AnIRLreferencetableexistsforeachportgroupconfigured,and
isindexedsimilarlytoportresources,asportgroup#,port‐type,reference.IRLreferencesarenot
populatedwithlimiters(resources),butcanbeconfiguredbytheuser.TheIRL
referencetablecan
bedisplayedusingtheshowcosreferencecommand.
Example
IntheCoSIRLreferencemappingtableforportgroups1.0and2.0,createareferencefortheIRL
resourcenumber1createdforeachgroup.Thereferencenumber1isused.
B3(su)->set cos reference irl 1.0 1 rate-limit 1
B3(su)->set cos reference irl 2.0 1 rate-limit 1
irl SpecifiesthatanIRLreferenceisbeingconfigured.
group‐type‐index Specifiesaninboundratelimitingportgroup/typeindex.Validentriesare
intheformofgroup#.port‐type.
Validvaluesforgroup#canrangefrom0to7.Validvaluesforport‐type
canrangefrom0to1,althoughonly
porttype0iscurrentlysupported.
Forexample,portgroup3wouldbespecifiedas3.0.
reference IRLreferencenumberassociatedwiththisentry.
rate‐limitirl‐index Ratelimiter(IRLresourceindex)tobindthisreferenceto.Validvalues
rangefrom0to99.

Enterasys SecureStack B3 Specifications

General

Ports	24 or 48 10/100/1000BASE-T ports
Forwarding Rate	95.2 Mpps
Layer	Layer 2/3
Power Supply	Internal
Redundant Power Supply	Optional
VLANs Supported	4094
Uplink Ports	4 SFP ports
Dimensions	44.0 x 43.7 x 4.4 cm
Weight	11.9 lbs (5.4 kg)
MAC Address Table Size	16, 000 entries
Jumbo Frame Support	Up to 9, 216 bytes
Power over Ethernet	PoE+
Operating Temperature	0°C to 50°C
Storage Temperature	-20 °C to 70 °C
Humidity	10% to 95% (non-condensing)
