Downloading a New Firmware Image
SecureStack B3 Configuration Guide 3-35
Downloading via the Serial Port
Todownloadswitchfirmwareviatheserial(console)port,proceedasfollows:
1. Withtheconsoleportconnected,poweruptheswitch.Thefollowingmessagedisplays:
Version 01.00.29 05-09-2005
Computing MD5 Checksum of operational code...
Select an option. If no selection in 2 seconds then
operational code will start.
1 - Start operational code.
2 - Start Boot Menu.
Select (1, 2):2
Password: *************
2. Beforethebootupcompletes,type2toselect“StartBootMenu”.Use“administrator”forthe
Password.
Boot Menu Version 01.00.29 05-09-2005
Options available
1 - Start operational code
2 - Change baud rate
3 - Retrieve event log using XMODEM (64KB).
4 - Load new operational code using XMODEM
5 - Display operational code vital product data
6 - Run Flash Diagnostics
7 - Update Boot Code
8 - Delete operational code
9 - Reset the system
10 - Restore Configuration to factory defaults (delete config files)
11 - Set new Boot Code password
[Boot Menu] 2
3. Type2.Thefoll owingbaudrateselectionscreendisplays:
1 - 1200
2 - 2400
3 - 4800
4 - 9600
5 - 19200
6 - 38400
7 - 57600
8 - 115200
0 - no change
4. Type8tosettheswitchbaudrateto115200.Thefollowingmessagedisplays:
Setting baud rate to 115200, you must change your terminal baud rate.
5. Settheterminalbaudrateto115200andpressENTER.
Note: The above “Boot Menu” password “administrator” can be changed using boot menu option
11.
