show host vlan

SecureStack B3 Configuration Guide 8-17

Commands.

show host vlan

UsethiscommandtodisplaythecurrenthostVLAN.

Syntax

show host vlan

Parameters

None.

Defaults

None.

Mode

Switchcommand,read‐only.

Example

ThisexampleshowshowtodisplaythehostVLAN:

B3(su)->show host vlan

Host vlan is 7.

set host vlan

UsethiscommandtoassignhoststatustoaVLAN.

Syntax

set host vlan vlan-id

Parameters

Defaults

None.

Note: The host port is the management entity of the device. Refer to “Creating a Secure

Management VLAN” on page 8-1 for more information.

For information about... Refer to page...

show host vlan 8-17

set host vlan 8-17

clear host vlan 8-18

vlan‐id SpecifiesthenumberoftheVLANtosetasthehostVLAN.
