Enterasys SecureStack B3

To Next Page

To Previous Page

show pwa banner

20-60 Security Configuration

Parameters

Defaults

None.

Mode

Switchcommand,read‐write.

Example

Thisexampleshowshowtoenableportwebauthentication:

B3(su)->set pwa enable

show pwa banner

Usethiscommandtodisplaytheportwebauthenticationloginbannerstring.

Syntax

show pwa banner

Parameters

None.

Defaults

None.

Mode

Switchcommand,read‐only.

Example

ThisexampleshowshowtodisplaythePWAloginbanner:

B3(su)->show pwa banner

Welcome to Enterasys Networks

set pwa banner

UsethiscommandtoconfigureastringtobedisplayedasthePWAloginbanner.

Syntax

set pwa banner string

enable|disable Enablesordisablesportwebauthentication.
