set ciscodp port
SecureStack B3 Configuration Guide 4-11
Parameters
Defaults
Status:enabled
VoiceVLAN:none
Trustmode:trusted
CoSvalue:0
Mode
Switchmode,read‐write.
Usage
ThefollowingpointsdescribehowtheCiscoDPextendedtrustsettingsworkontheswitch.
•ACiscoDPporttruststatusoftrustedoruntrustedisonlymeaningfulwhenaCiscoIPphone
isconnectedtoaswi tchportandaPCorotherdeviceisconnectedtothebackof
theCiscoIP
phone.
•ACiscoDPportstateoftrustedoruntrustedonlyaffectstaggedtraffictransmittedbythe
deviceconnectedtotheCiscoIPphone.Untaggedtraffictransmitted bythedeviceconnected
totheCiscoIPphoneisunaffectedbythissetting.
•Iftheswitchportisconfiguredto
aCiscoDPtruststateoftrusted(withthetrustedyes
parameterofthiscommand),thissettingiscommunicatedtotheCiscoIPphoneinstructingit
toallowthedeviceconnectedtoittotransmittrafficcontaininganyCoSorLayer2802.1p
marking.
status SetstheCiscoDPportoperationalstatus.
disable DoesnottransmitorprocessCiscoDPPDUs.
enable TransmitsandprocessesCiscoDPPDUs.
vvid SetstheportvoiceVLANforCiscoDPPDUtransmission.
vlan‐id SpecifiestheVLANID,range1‐4094.
none NovoiceVLANwillbeusedinCiscoDPPDUs.Thisisthedefault.
dot1p Instructsattachedphonetosend802.1ptaggedframes.
untagged Instructsattachedphonetosenduntaggedframes.
trusted Setstheextendedtrustmodeontheport.
yes Instructsattachedphonetoallowthedeviceconnectedtoittotransmit
trafficcontaininganyCoS orLayer2802.1pmarking.Thisisthedefault
value.
no Instructsattachedphonetooverwritethe802.1ptagof
traffic
transmittedbythedeviceconnectedtoitto0,bydefault,ortothevalue
configuredwiththecosparameter.
cosvalue Instructsattachedphonetooverwritethe802.1ptagoftraffic
transmittedbythedeviceconnectedtoitwiththespecifiedvalue,when
thetrustmodeoftheport
issettountrusted.Valuecanrangefrom0to
7,with0indicatingthelowestpriority.
port‐string Specifiestheport(s)onwhichstatuswillbeset.
