RM0390 Rev 4 1143/1328
RM0390 USB on-the-go full-speed/high-speed (OTG_FS/OTG_HS)
1264
31.15.15 OTG host periodic transmit FIFO size register
(OTG_HPTXFSIZ)
Address offset: 0x100
Reset value: 0x0200 0400
31.15.16 OTG device IN endpoint transmit FIFO size register
(OTG_DIEPTXFx) (x = 1..5[FS] /8[HS], where x is the
FIFO number)
Address offset: 0x104 + (x – 1) * 0x04
Reset values:
0x0200 0200 + (x * 0x200)
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
PTXFSIZ[15:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
1514131211109876543210
PTXSA[15:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:16 PTXFD[15:0]: Host periodic Tx FIFO depth
This value is in terms of 32-bit words.
Minimum value is 16
Bits 15:0 PTXSA[15:0]: Host periodic Tx FIFO start address
This field configures the memory start address for periodic transmit FIFO RAM.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
INEPTXFD[15:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
1514131211109876543210
INEPTXSA[15:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:16 INEPTXFD[15:0]: IN endpoint Tx FIFO depth
This value is in terms of 32-bit words.
Minimum value is 16
Bits 15:0 INEPTXSA[15:0]: IN endpoint FIFOx transmit RAM start address
This field contains the memory start address for IN endpoint transmit FIFOx. The address
must be aligned with a 32-bit memory location.
