RM0390 Rev 4 1105/1328
RM0390 USB on-the-go full-speed/high-speed (OTG_FS/OTG_HS)
1264
31.14 OTG_FS/OTG_HS control and status registers
By reading from and writing to the control and status registers (CSRs) through the AHB
slave interface, the application controls the OTG_FS/OTG_HS controller. These registers
are 32 bits wide, and the addresses are 32-bit block aligned. The OTG_FS/OTG_HS
registers must be accessed by words (32 bits).
CSRs are classified as follows:
• Core global registers
• Host-mode registers
• Host global registers
• Host port CSRs
• Host channel-specific registers
• Device-mode registers
• Device global registers
• Device endpoint-specific registers
• Power and clock-gating registers
• Data FIFO (DFIFO) access registers
Only the core global, power and clock-gating, data FIFO access, and host port control and
status registers can be accessed in both host and device modes. When the
OTG_FS/OTG_HS controller is operating in one mode, either device or host, the application
must not access registers from the other mode. If an illegal access occurs, a mode
mismatch interrupt is generated and reflected in the core interrupt register (MMIS bit in the
OTG_GINTSTS register). When the core switches from one mode to the other, the registers
in the new mode of operation must be reprogrammed as they would be after a power-on
reset.
31.14.1 CSR memory map
The host and device mode registers occupy different addresses. All registers are
implemented in the AHB clock domain.
Global CSR map
These registers are available in both host and device modes.
Table 223. Core global control and status registers (CSRs)
Acronym
Address
offset
Register name
OTG_GOTGCTL 0x000 Section 31.15.1: OTG control and status register (OTG_GOTGCTL)
OTG_GOTGINT 0x004 Section 31.15.2: OTG interrupt register (OTG_GOTGINT)
OTG_GAHBCFG 0x008 Section 31.15.3: OTG AHB configuration register (OTG_GAHBCFG)
OTG_GUSBCFG 0x00C Section 31.15.4: OTG USB configuration register (OTG_GUSBCFG)
OTG_GRSTCTL 0x010 Section 31.15.5: OTG reset register (OTG_GRSTCTL)
OTG_GINTSTS 0x014 Section 31.15.6: OTG core interrupt register (OTG_GINTSTS)
OTG_GINTMSK 0x018 Section 31.15.7: OTG interrupt mask register (OTG_GINTMSK)
