RM0390 Rev 4 207/1328
RM0390 Direct memory access controller (DMA)
237
Table 28. DMA1 request mapping
Peripheral
requests
Stream 0 Stream 1 Stream 2 Stream 3 Stream 4 Stream 5 Stream 6 Stream 7
Channel 0 SPI3_RX SPDIFRX_DT SPI3_RX SPI2_RX SPI2_TX SPI3_TX SPDIFRX_CS SPI3_TX
Channel 1 I2C1_RX I2C3_RX TIM7_UP - TIM7_UP I2C1_RX I2C1_TX I2C1_TX
Channel 2 TIM4_CH1 - FMPI2C1_RX TIM4_CH2 - FMPI2C1_RX TIM4_UP TIM4_CH3
Channel 3 -
TIM2_UP
TIM2_CH3
I2C3_RX - I2C3_TX TIM2_CH1
TIM2_CH2
TIM2_CH4
TIM2_UP
TIM2_CH4
Channel 4 UART5_RX USART3_RX UART4_RX USART3_TX UART4_TX USART2_RX USART2_TX UART5_TX
Channel 5 - -
TIM3_CH4
TIM3_UP
-
TIM3_CH1
TIM3_TRIG
TIM3_CH2 - TIM3_CH3
Channel 6
TIM5_CH3
TIM5_UP
TIM5_CH4
TIM5_TRIG
TIM5_CH1
TIM5_CH4
TIM5_TRIG
TIM5_CH2 - TIM5_UP -
Channel 7 - TIM6_UP I2C2_RX I2C2_RX USART3_TX DAC1 DAC2 I2C2_TX
Table 29. DMA2 request mapping
Peripheral
requests
Stream 0 Stream 1 Stream 2 Stream 3 Stream 4 Stream 5 Stream 6 Stream 7
Channel 0 ADC1 SAI1_A
TIM8_CH1
TIM8_CH2
TIM8_CH3
SAI1_A ADC1 SAI1_B
TIM1_CH1
TIM1_CH2
TIM1_CH3
SAI2_B
Channel 1 - DCMI ADC2 ADC2 SAI1_B - - DCMI
Channel 2 ADC3 ADC3 - - - - - -
Channel 3 SPI1_RX - SPI1_RX SPI1_TX SAI2_A SPI1_TX SAI2_B QUADSPI
Channel 4 SPI4_RX SPI4_TX USART1_RX SDIO USART1_RX SDIO USART1_TX
Channel 5 - USART6_RX USART6_RX SPI4_RX SPI4_TX - USART6_TX USART6_TX
Channel 6 TIM1_TRIG TIM1_CH1 TIM1_CH2 TIM1_CH1
TIM1_CH4
TIM1_TRIG
TIM1_COM
TIM1_UP TIM1_CH3 -
Channel 7 - TIM8_UP TIM8_CH1 TIM8_CH2 TIM8_CH3 - -
TIM8_CH4
TIM8_TRIG
TIM8_COM
