ST STM32F446 Series User Manual

RM0390 Rev 4 1177/1328
RM0390 USB on-the-go full-speed/high-speed (OTG_FS/OTG_HS)
1264
31.15.49 OTG device IN endpoint x interrupt register (OTG_DIEPINTx)
(x = 0..5[FS] /8[HS], where x = Endpoint number)
Address offset: 0x908 + (x * 0x20)
Reset value: 0x0000 0080
This register indicates the status of an endpoint with respect to USB- and AHB-related
events. It is shown in Figure 409. The application must read this register when the IN
endpoints interrupt bit of the core interrupt register (IEPINT in OTG_GINTSTS) is set.
Before the application can read this register, it must first read the device all endpoints
interrupt (OTG_DAINT) register to get the exact endpoint number for the device endpoint-x
interrupt register. The application must clear the appropriate bit in this register to clear the
corresponding bits in the OTG_DAINT and OTG_GINTSTS registers.
Note: Configuration register for USB OTG FS
Bit 16 EONUM: Even/odd frame
Applies to isochronous IN endpoints only.
Indicates the frame number in which the core transmits/receives isochronous data for this
endpoint. The application must program the even/odd frame number in which it intends to
transmit/receive isochronous data for this endpoint using the SEVNFRM and SODDFRM
fields in this register.
0: Even frame
1: Odd frame
DPID: Endpoint data PID
Applies to interrupt/bulk IN endpoints only.
Contains the PID of the packet to be received or transmitted on this endpoint. The
application must program the PID of the first packet to be received or transmitted on this
endpoint, after the endpoint is activated. The application uses the SD0PID register field to
program either DATA0 or DATA1 PID.
0: DATA0
1: DATA1
Bit 15 USBAEP: USB active endpoint
Indicates whether this endpoint is active in the current configuration and interface. The core
clears this bit for all endpoints (other than EP 0) after detecting a USB reset. After receiving
the SetConfiguration and SetInterface commands, the application must program endpoint
registers accordingly and set this bit.
Bits 14:11 Reserved, must be kept at reset value.
Bits 10:0 MPSIZ[10:0]: Maximum packet size
The application must program this field with the maximum packet size for the current logical
endpoint. This value is in bytes.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. NAK Res.
PKTD
RPSTS
Res. Res.
TXFIF
OUD
RN
TXFE
IN
EPNE
IN
EPNM
ITTXFE TOC Res.
EP
DISD
XFRC
rc_w1 rc_w1 rc_w1 r r rc_w1 rc_w1 rc_w1 rc_w1 rc_w1
