RM0390 Rev 4 1279/1328
RM0390 HDMI-CEC controller (HDMI-CEC)
1283
32.7.3 CEC Tx data register (CEC_TXDR)
Address offset: 0x8
Reset value: 0x0000 0000
32.7.4 CEC Rx Data Register (CEC_RXDR)
Address offset: 0xC
Reset value: 0x0000 0000
32.7.5 CEC Interrupt and Status Register (CEC_ISR)
Address offset: 0x10
Reset value: 0x0000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. TXD[7:0]
wwwwwwww
Bits 31:8 Reserved, must be kept at reset value.
Bits 7:0 TXD[7:0]: Tx Data register.
TXD is a write-only register containing the data byte to be transmitted.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. RXD[7:0]
rrrrrrrr
Bits 31:8 Reserved, must be kept at reset value.
Bits 7:0 RXD[7:0]: Rx Data register.
RXD is read-only and contains the last data byte which has been received from the CEC line.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Res. Res. Res.
TX
ACKE
TX
ERR
TX
UDR
TX
END
TXBR
ARB
LST
RX
ACKE
LBPE SBPE BRE
RX
OVR
RX
END
RXBR
rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1
