ST STM32F446 Series User Manual

RM0390 Rev 4 1155/1328
RM0390 USB on-the-go full-speed/high-speed (OTG_FS/OTG_HS)
1264
31.15.28 OTG host channel x interrupt mask register (OTG_HCINTMSKx)
(x = 0..15[HS] / 11[FS], where x = Channel number)
Address offset: 0x50C + (x * 0x20)
Reset value: 0x0000 0000
This register reflects the mask for each channel status described in the previous section.
Note: Configuration register for USB OTG FS
Note: Configuration register for USB OTG HS
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res.
DTERR
M
FRM
ORM
BBERR
M
TXERR
M
Res. ACKM NAKM
STALL
M
Res. CHHM
XFRC
M
rw rw rw rw rw rw rw rw rw
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res.
DTERR
M
FRM
ORM
BBERR
M
TXERR
M
NYET ACKM NAKM
STALL
M
AHB
ERRM
CHHM
XFRC
M
rw rw rw rw rw rw rw rw
rw
rw rw
Bits 31:11 Reserved, must be kept at reset value.
Bit 10 DTERRM: Data toggle error mask.
0: Masked interrupt
1: Unmasked interrupt
Bit 9 FRMORM: Frame overrun mask.
0: Masked interrupt
1: Unmasked interrupt
Bit 8 BBERRM: Babble error mask.
0: Masked interrupt
1: Unmasked interrupt
Bit 7 TXERRM: Transaction error mask.
0: Masked interrupt
1: Unmasked interrupt
Bit 6 Reserved, must be kept at reset value for USB OTG FS.
Bit 6 NYET: response received interrupt mask for USB OTG HS.
0: Masked interrupt
1: Unmasked interrupt
