Flexible memory controller (FMC) RM0390
306/1328 RM0390 Rev 4
11.7 SDRAM controller
11.7.1 SDRAM controller main features
The main features of the SDRAM controller are the following:
• Two SDRAM banks with independent configuration
• 8-bit, 16-bit data bus width
• 13-bits Address Row, 11-bits Address Column, 4 internal banks: 4x16Mx16bit
(128 MB), 4x16Mx8bit (64 MB)
• Word, half-word, byte access
• SDRAM clock can be HCLK/2 or HCLK/3
• Automatic row and bank boundary management
• Multibank ping-pong access
• Programmable timing parameters
• Automatic Refresh operation with programmable Refresh rate
• Self-refresh mode
• Power-down mode
• SDRAM power-up initialization by software
• CAS latency of 1,2,3
• Cacheable Read FIFO with depth of 6 lines x32-bit (6 x14-bit address tag)
11.7.2 SDRAM External memory interface signals
At startup, the SDRAM I/O pins used to interface the FMC SDRAM controller with the
external SDRAM devices must configured by the user application. The SDRAM controller
I/O pins which are not used by the application, can be used for other purposes.
Table 79. SDRAM signals
SDRAM signal
I/O
type
Description Alternate function
SDCLK O SDRAM clock -
SDCKE[1:0] O
SDCKE0: SDRAM Bank 1 Clock Enable
SDCKE1: SDRAM Bank 2 Clock Enable
-
SDNE[1:0] O
SDNE0: SDRAM Bank 1 Chip Enable
SDNE1: SDRAM Bank 2 Chip Enable
-
A[12:0] O Address FMC_A[12:0]
D[15:0] I/O Bidirectional data bus FMC_D[15:0]
BA[1:0] O Bank Address FMC_A[15:14]
NRAS O Row Address Strobe -
NCAS O Column Address Strobe -
SDNWE O Write Enable -
NBL[1:0] O
Output Byte Mask for write accesses
(memory signal name: DQM[1:0]
FMC_NBL[1:0]
