Fast-mode Plus Inter-integrated circuit (FMPI2C) interface RM0390
750/1328 RM0390 Rev 4
23.7.5 Timing register (FMPI2C_TIMINGR)
Address offset: 0x10
Reset value: 0x0000 0000
Access: No wait states
Note: This register must be configured when the FMPI2C is disabled (PE = 0).
Note: The STM32CubeMX tool calculates and provides the I2C_TIMINGR content in the I2C
Configuration window.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
PRESC[3:0] Res. Res. Res. Res. SCLDEL[3:0] SDADEL[3:0]
rw rw rw
15141312111098 7 654321 0
SCLH[7:0] SCLL[7:0]
rw rw
Bits 31:28 PRESC[3:0]: Timing prescaler
This field is used to prescale FMPI2CCLK in order to generate the clock period t
PRESC
used for
data setup and hold counters (refer to FMPI2C timings on page 697) and for SCL high and low
level counters (refer to FMPI2C master initialization on page 712).
t
PRESC
= (PRESC+1) x t
I2CCLK
Bits 27:24 Reserved, must be kept at reset value.
Bits 23:20 SCLDEL[3:0]: Data setup time
This field is used to generate a delay t
SCLDEL
between SDA edge and SCL rising edge. In
master mode and in slave mode with NOSTRETCH = 0, the SCL line is stretched low during
t
SCLDEL
.
t
SCLDEL
= (SCLDEL+1) x t
PRESC
Note: t
SCLDEL
is used to generate t
SU:DAT
timing.
Bits 19:16 SDADEL[3:0]: Data hold time
This field is used to generate the delay t
SDADEL
between SCL falling edge and SDA edge. In
master mode and in slave mode with NOSTRETCH = 0, the SCL line is stretched low during
t
SDADEL
.
t
SDADEL
= SDADEL x t
PRESC
Note: SDADEL is used to generate t
HD:DAT
timing.
Bits 15:8 SCLH[7:0]: SCL high period (master mode)
This field is used to generate the SCL high period in master mode.
t
SCLH
= (SCLH+1) x t
PRESC
Note: SCLH is also used to generate t
SU:STO
and t
HD:STA
timing.
Bits 7:0 SCLL[7:0]: SCL low period (master mode)
This field is used to generate the SCL low period in master mode.
t
SCLL
= (SCLL+1) x t
PRESC
Note: SCLL is also used to generate t
BUF
and t
SU:STA
timings.
