USB on-the-go full-speed/high-speed (OTG_FS/OTG_HS) RM0390
1170/1328 RM0390 Rev 4
31.15.43 OTG device each endpoint interrupt register (OTG_DEACHINT)
Address offset: 0x0838
Reset value: 0x0000 0000
Note: Configuration register applies only to USB OTG HS.
31.15.44 OTG device each endpoint interrupt mask register
(OTG_DEACHINTMSK)
Address offset: 0x083C
Reset value: 0x0000 0000
There is one interrupt bit for endpoint 1 IN and one interrupt bit for endpoint 1 OUT.
Note: Configuration register applies only to USB OTG HS
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
OEP1
INT
Res.
r
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
IEP1
INT
Res.
r
Bits 31:18 Reserved, must be kept at reset value.
Bit 17 OEP1INT: OUT endpoint 1 interrupt bit
Bits 16:2 Reserved, must be kept at reset value.
Bit 1 IEP1INT: IN endpoint 1interrupt bit
Bit 0 Reserved, must be kept at reset value.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
OEP1
INTM
Res.
rw
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
IEP1I
NTM
Res.
rw
Bits 31:18 Reserved, must be kept at reset value.
Bit 17 OEP1INTM: OUT endpoint 1 interrupt mask bit
Bits 16:2 Reserved, must be kept at reset value.
Bit 1 IEP1INTM: IN endpoint 1 interrupt mask bit
Bit 0 Reserved, must be kept at reset value.
