ECC result registers (FMC_ECCR)
Address offset: 0x94
Reset value: 0x0000 0000
This register contain the current error correction code value computed by the ECC
computation modules of the FMC NAND controller. When the CPU reads the data from a
NAND Flash memory page at the correct address (refer to Section 11.6.6: Computation of
the error correction code (ECC) in NAND Flash memory), the data read/written from/to the
NAND Flash memory are processed automatically by the ECC computation module. When
X bytes have been read (according to the ECCPS field in the FMC_PCR registers), the CPU
must read the computed ECC value from the FMC_ECC registers. It then verifies if these
computed parity data are the same as the parity value recorded in the spare area, to
determine whether a page is valid, and, to correct it otherwise. The FMC_ECCR register
should be cleared after being read by setting the ECCEN bit to ‘0’. To compute a new data
block, the ECCEN bit must be set to ’1’.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
ECCx
rrrrrrrrrrrrrrrr
1514131211109876543210
ECCx
rrrrrrrrrrrrrrrr
Bits 31:0 ECC: ECC result
This field contains the value computed by the ECC computation logic. Table 78 describes
the contents of these bit fields.
Table 78. ECC result relevant bits
ECCPS[2:0] Page size in bytes ECC bits
000 256 ECC[21:0]
001 512 ECC[23:0]
010 1024 ECC[25:0]
011 2048 ECC[27:0]
100 4096 ECC[29:0]
101 8192 ECC[31:0]
