RM0390 Rev 4 925/1328
RM0390 SPDIF receiver interface (SPDIFRX)
929
27.5.6 Data input register (SPDIFRX_FMT1_DR)
Address offset: 0x10
Reset value: 0x0000 0000
This register can take 3 different formats according to DRFMT. Here is the format when
DRFMT = 0b01:
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
DR[23:8]
rrrrrrrrrrrrrrrr
1514131211109876543210
DR[7:0] Res. Res. PT[1:0] C U V PE
rrrrrrrr rrrrrr
Bits 31:8 DR[23:0]: Data value
Contains the 24 received data bits, aligned on D[23]
Bits 7:6 Reserved, must be kept at reset value.
Bits 5:4 PT[1:0]: Preamble Type
These bits indicate the preamble received.
00: not used
01: Preamble B received
10: Preamble M received
11: Preamble W received
Note that if PTMSK = 1, this field is forced to zero
Bit 3 C: Channel Status bit
Contains the received channel status bit, if CUMSK = 0, otherwise it is forced to 0
Bit 2 U: User bit
Contains the received user bit, if CUMSK = 0, otherwise it is forced to 0
Bit 1 V: Validity bit
Contains the received validity bit if VMSK = 0, otherwise it is forced to 0
Bit 0 PE: Parity Error bit
Contains a copy of PERR bit if PMSK = 0, otherwise it is forced to 0
