Flexible memory controller (FMC) RM0390
256/1328 RM0390 Rev 4
The application software uses the 3 sections to access the NAND Flash memory:
• To sending a command to NAND Flash memory, the software must write the
command value to any memory location in the command section.
• To specify the NAND Flash address that must be read or written, the software
must write the address value to any memory location in the address section. Since an
address can be 4 or 5 bytes long (depending on the actual memory size), several
consecutive write operations to the address section are required to specify the full
address.
• To read or write data, the software reads or writes the data from/to any memory
location in the data section.
Since the NAND Flash memory automatically increments addresses, there is no need to
increment the address of the data section to access consecutive memory locations.
11.4.3 SDRAM address mapping
The HADDR[28] bit (internal AHB address line 28) is used to select one of the two memory
banks as indicated in Table 44.
The following table shows SDRAM mapping for a 13-bit row, a 11-bit column and a 4 internal
bank configuration.
Table 43. NAND bank selection
Section name HADDR[17:16] Address range
Address section 1X 0x020000-0x03FFFF
Command section 01 0x010000-0x01FFFF
Data section 00 0x000000-0x0FFFF
Table 44. SDRAM bank selection
HADDR[28] Selected bank Control register Timing register
0 SDRAM Bank1 FMC_SDCR1 FMC_SDTR1
1 SDRAM Bank2 FMC_SDCR2 FMC_SDTR2
Table 45. SDRAM address mapping
Memory width
(1)
1. When interfacing with a 16-bit memory, the FMC internally uses the HADDR[11:1] internal AHB address
lines to generate the external address. Whatever the memory width, FMC_A[0] has to be connected to the
external memory address A[0].
Internal bank Row address
Column
address
(2)
2. The AutoPrecharge is not supported. FMC_A[10] must be connected to the external memory address
A[10] but it will be always driven ‘low’.
Maximum
memory capacity
(Mbytes)
8-bit HADDR[25:24] HADDR[23:11] HADDR[10:0]
64 Mbytes:
4 x 8K x 2K
16-bit HADDR[26:25] HADDR[24:12] HADDR[11:1]
128 Mbytes:
4 x 8K x 2K x 2
