ST STM32WL5 Series User Manual

Real-time clock (RTC) RM0453
1032/1461 RM0453 Rev 1
32.6.15 RTC alarm A sub second register (RTC_ALRMASSR)
This register can be written only when ALRAE is reset in RTC_CR register, or in initialization
mode.
Address offset: 0x44
Backup domain reset value: 0x0000 0000
System reset: not affected
Bit 7 MSK1: Alarm A seconds mask
0: Alarm A set if the seconds match
1: Seconds don’t care in alarm A comparison
Bits 6:4 ST[2:0]: Second tens in BCD format.
Bits 3:0 SU[3:0]: Second units in BCD format.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
SSCLR Res. MASKSS[5:0] Res. Res. Res. Res. Res. Res. Res. Res.
rw rw rw rw rw rw rw
1514131211109876543210
Res. SS[14:0]
rw rw rw rw rw rw rw rw rw rw rw rw w rw rw
Bit 31 SSCLR: Clear synchronous counter on alarm (Binary mode only)
0: The synchronous binary counter (SS[31:0] in RTC_SSR) is free-running.
1: The synchronous binary counter (SS[31:0] in RTC_SSR) is running from 0xFFFF FFFF to
RTC_ALRMABINR → SS[31:0] value and is automatically reloaded with 0xFFFF FFFF when
reaching RTC_ALRMABINR → SS[31:0].
Note: SSCLR must be kept to 0 when BCD or mixed mode is used (BIN = 00, 10 or 11).
Bit 30 Reserved, must be kept at reset value.
Bits 29:24 MASKSS[5:0]: Mask the most-significant bits starting at this bit
0: No comparison on sub seconds for Alarm A. The alarm is set when the seconds unit is
incremented (assuming that the rest of the fields match).
1: SS[31:1] are don’t care in Alarm A comparison. Only SS[0] is compared.
2: SS[31:2] are don’t care in Alarm A comparison. Only SS[1:0] are compared.
...
31: SS[31] is don’t care in Alarm A comparison. Only SS[30:0] are compared.
From 32 to 63: All 32 SS bits are compared and must match to activate alarm.
Note: In BCD mode (BIN=00) the overflow bits of the synchronous counter (bits 31:15) are
never compared. These bits can be different from 0 only after a shift operation.
Bits 23:15 Reserved, must be kept at reset value.
Bits 14:0 SS[14:0]: Sub seconds value
This value is compared with the contents of the synchronous prescaler counter to determine
if alarm A is to be activated. Only bits 0 up MASKSS-1 are compared.
This field is the mirror of SS[14:0] in the RTC_ALRMABINR, and so can also be read or
written through RTC_ALRMABINR.
