Debug support (DBG) RM0453
1360/1461 RM0453 Rev 1
38.6.17 DWT CoreSight component identity register 0 (DWT_CIDR0)
Address offset: 0xFF0
Reset value: 0x0000 000D
38.6.18 DWT CoreSight peripheral identity register 1 (DWT_CIDR1)
Address offset: 0xFF4
Reset value: 0x0000 00E0
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. PREAMBLE[7:0]
rrrrrrrr
Bits 31:8 Reserved, must be kept at reset value.
Bits 7:0 PREAMBLE[7:0]: component ID bits [7:0]
0x0D: Common ID value
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. CLASS[3:0] PREAMBLE[11:8]
rrrrrrrr
Bits 31:8 Reserved, must be kept at reset value.
Bits 7:4 CLASS[3:0]: component ID bits [15:12] - component class
0xE: Trace generator component
Bits 3:0 PREAMBLE[11:8]: component ID bits [11:8]
0x0: Common ID value
