Comparator (COMP) RM0453

626/1461 RM0453 Rev 1

Figure 95. Window mode

21.3.6 Hysteresis

The comparator includes a programmable hysteresis to avoid spurious output transitions in

case of noisy signals. The hysteresis can be disabled if it is not needed (for instance when

exiting from low-power mode) to be able to force the hysteresis value using external

components.

Figure 96. Comparator hysteresis

MSv37667V1

COMPy_INM I/Os

COMPy_INP I/Os

Internal sources

COMPy_INP

COMPy_INM

COMPy_INMSEL

COMPy

WINMODE

COMPx_INM I/Os

COMPx_INP I/Os

Internal sources

COMPx_INP

COMPx_INM

COMPx_INPSEL

COMPx_INMSEL

COMPx

COMPx_INPSEL

COMPx_INM I/Os

COMPx_INMESEL

COMPy_INMESEL

COMPy_INM I/Os

MS19984V1

INP

INM

INM - V

hyst

COMP_OUT
