RM0453 Rev 1 1285/1461

RM0453 Serial peripheral interface / integrated interchip sound (SPI/I2S)

1323

Figure 357. Slave full-duplex communication

Assumptions for slave full-duplex communication example:

• Data size > 8 bit

If DMA is used:

• Number of Tx frames transacted by DMA is set to 3

• Number of Rx frames transacted by DMA is set to 3

See also : Communication diagrams on page 1283 for details about common assumptions

and notes.

DTx1

DRx1

NSS

SCK

BSY

MISO

MSB

MSB MSB

DTx2

DTx3

SPE

TXE

11 11 00

FTLVL

DTx1

DTx2

LSB

DRx2

LSB

DRx3

LSB

10 0010 0000 00

RXNE

DRx1

DRx2 DRx3

FRLVL

DMA Tx TICF

DMA Rx TICF

Enable Tx/Rx DMA or interrupts

DMA or software control at Tx events

DMA or software control at Rx events

DTx3

MOSI

MSv32123V2
