RM0453 Rev 1 695/1461
RM0453 AES hardware accelerator (AES)
698
23.7.13 AES key register 4 (AES_KEYR4)
Address offset: 0x30
Reset value: 0x0000 0000
23.7.14 AES key register 5 (AES_KEYR5)
Address offset: 0x34
Reset value: 0x0000 0000
23.7.15 AES key register 6 (AES_KEYR6)
Address offset: 0x38
Reset value: 0x0000 0000
Bits 31:0 IVI[127:96]: Initialization vector input, bits [127:96]
Refer to the AES_IVR0 register for description of the IVI[128:0] bitfield.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
KEY[159:144]
wwwwwwwwwwwwwwww
1514131211109876543210
KEY[143:128]
wwwwwwwwwwwwwwww
Bits 31:0 KEY[159:128]: Cryptographic key, bits [159:128]
Refer to the AES_KEYR0 register for description of the KEY[255:0] bitfield.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
KEY[191:176]
wwwwwwwwwwwwwwww
1514131211109876543210
KEY[175:160]
wwwwwwwwwwwwwwww
Bits 31:0 KEY[191:160]: Cryptographic key, bits [191:160]
Refer to the AES_KEYR0 register for description of the KEY[255:0] bitfield.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
KEY[223:208]
wwwwwwwwwwwwwwww
1514131211109876543210
KEY[207:192]
wwwwwwwwwwwwwwww
Bits 31:0 KEY[223:192]: Cryptographic key, bits [223:192]
Refer to the AES_KEYR0 register for description of the KEY[255:0] bitfield.
