Extended interrupts and event controller (EXTI) RM0453
520/1461 RM0453 Rev 1
16.6.9 EXTI interrupt mask register (EXTI_CnIMR1)
Address offset: Block 1: 0x080
Address offset: Block 2: 0x0C0
Reset value: 0x0000 0000
16.6.10 EXTI event mask register (EXTI_CnEMR1)
Address offset: Block 1: 0x084
Address offset: Block 2: 0x0C4
Reset value: 0x0000 0000
Bits 31:14 Reserved, must be kept at reset value.
Bit 13 PIF45: pending bit on event input 45
These bits are set when the selected edge event or an EXTI_SWIER software trigger arrives
on the configurable event line. This bit is cleared by writing 1 to it.
0: No trigger request occurred.
1: Trigger request occurred.
Bits 12:10 Reserved, must be kept at reset value.
Bit 9 PIF41: pending bit on event input 41
Bit 8 PIF40: pending bit on event input 40
Bits 7:3 Reserved, must be kept at reset value.
Bit 2 PIF34: pending bit on event input 34
Bits 1:0 Reserved, must be kept at reset value.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
IM[31:16]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
1514131211109876543210
IM[15:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:0 IM[31:0]: wakeup with interrupt mask on event input x (x= 31 to 0)
For each bit of this field:
0: Wakeup with interrupt request from line x is masked.
1: Wakeup with Interrupt request from line x is unmasked.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. EM22 EM21 EM20 EM19 EM18 EM17 Res.
rw rw rw rw rw rw
1514131211109876543210
EM15 EM14 EM13 EM12 EM11 EM10 EM9 EM8 EM7 EM6 EM5 EM4 EM3 EM2 EM1 EM0
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
