Serial peripheral interface / integrated interchip sound (SPI/I2S) RM0453
1268/1461 RM0453 Rev 1
37.3 I2S main features
Half-duplex communication (only transmitter or receiver)
Master or slave operations
8-bit programmable linear prescaler to reach accurate audio sample frequencies (from
8 kHz to 192 kHz)
Data format may be 16-bit, 24-bit or 32-bit
Packet frame is fixed to 16-bit (16-bit data frame) or 32-bit (16-bit, 24-bit, 32-bit data
frame) by audio channel
Programmable clock polarity (steady state)
Underrun flag in slave transmission mode, overrun flag in reception mode (master and
slave) and Frame Error Flag in reception and transmitter mode (slave only)
16-bit register for transmission and reception with one data register for both channel
sides
Supported I
2
S protocols:
–I
2
S Philips standard
MSB-justified standard (left-justified)
LSB-justified standard (right-justified)
PCM standard (with short and long frame synchronization on 16-bit channel frame
or 16-bit data frame extended to 32-bit channel frame)
Data direction is always MSB first
DMA capability for transmission and reception (16-bit wide)
Master clock can be output to drive an external audio component. Ratio is fixed at
256 × F
S
(where F
S
is the audio sampling frequency)
37.4 SPI/I2S implementation
The following table describes all the SPI instances and their features embedded in the
devices.
Table 255. STM32WL5x SPI and SPI/I2S implementation
(1)
1. The SPI1 and SPI2S2 instances are general purpose type while the SUBGHZSPI instance is dedicated for
Sub-GHz radio control exclusively.
SPI Features SPI1 SPI2S2 SUBGHZSPI
Enhanced NSSP and TI modes Yes Yes Yes
Hardware CRC calculation Yes Yes No
I
2
S support No Yes No
Data size configurable from 4 to 16-bit from 4 to 16-bit from 4 to 16-bit
Rx/Tx FIFO size 32-bit 32-bit 32-bit
